INSTALLATION
DOWN LIGHT
SIZE
W203 x D203 x H120mm
CUT HOLE
185 x 185mm
POWER
10W, 15W, 20W, 25W, 30W
CCT
3000K, 4000K, 5700K
BEAM ANGLE
90˚
CRI
80↑
FINISH COLOR
WHITE / BLACK
BODY MATERIAL
Steel, Aluminum
REFLECTOR
PC
COVER
ACRYL
INPUT VOLTAGE
AC 220V / 50~60Hz
OUTPUT VOLTAGE
DC 36V
POWER FACTOR
90↑
IP RATING
20
OPERATING TEMPERATURE
-20 to +40℃
OPTION
Moisture Protection
ETC
Dali, 0-10, 1-10, Triac Dimming
